Task Drawing & Worksheet

resources Download this drawing(A copy of the finished drawing is stored in the Blocks palette)

Activity Overview

During this session you will learn about :

Assembling objects using a source and destination point.

Creating a wall thickness using Shell solid.

Creating profiles using 2D boolean functions

Combining the volume of solids using 3D Add.

Using artistic context to present the model.

Introducing

The following tools will be used during this Session :

Assembly by 3 Points.

Shell Solid.

Information

Artistic context A form of graphical element included to highlight certain features of the design  is added to highlight aspects of the model for presentation purposes and is entirely subject to individual preference

The solid green outline placed on the face of a solid when using the Shell tool is not displayed if Layer 0 is switched off.

The option to display Form Building Edge Display | Form Building Edgess is deactivated.

Estimated Duration

Approximately 35 minutes drawing time. Total session duration may vary.

FULL SESSION VIDEO

A video is provided for each individual Task of this Session, however a full session video is provided below.

This movie will open in a new window. To navigate back to this page, close the movie window.
