Task Drawing & Worksheet

resources Download this drawing(A copy of the finished drawing is stored in the Blocks palette)



Activity Overview

During this session you will learn about :

Sectioning a solid using the Workplane and a closed polyline.

Using the Facet Editor tool to modify the surface of an object.

Creating an offset from a contour.

Moving objects to the current Workplane.

Inserting holes which automatically subtract material.

Introducing

The following tools will be used during this Session :

Section by Closed Polyline

Facet Editor

Radial Copy – 3D

Place on Workplane

Offset

Create Holes

Information

Original profiles, used to draw both the pedestal and the chair should be retained in the blocks palette.

Some freehand drawing is necessary for this task.  Consequently, profiles and solids may differ in appearance.

Estimated Duration

Approximately 50 minutes drawing time. Total session duration may vary.

FULL SESSION VIDEO

A video is provided for each individual Task of this Session, however a full session video is provided below.

This movie will open in a new window. To navigate back to this page, close the movie window.
